Mostakbal Misr P.S 03
1st Stage - Reclamation
of 300,000 Feddan
Pumping Stattion 03
No. of Pumps: 11 units
Power Rating: 3500 KW/each
Under Construction
SHADER AZZAM DRAINAGE P.S
Pumps: CLT 800/1000-GANZ
Q= 2.0 m 3 /sec
H= 6 m
n= 495 RPM
P= 175 KW
QTY: 3 units
Scope of work:
Construction, supply, Commissioning and Startup on 2021
O&M: 2 Years
Barnees Desalination Plant
Location: South Red Sea
Capacity: 4000 m 3 / day
Scope of Work:
Turnkey Construction Project, commissioning and start-up on 2019
Supply & erection of GLS tanks; Different sizes, from 60 m3 to 2000 m 3
Cleopatra Desalination Plant
Location:Marsa Matrouh City
Capacity:3000 m 3 / day
Scope of Work:
Special civil works
Commissioning and start-up on 2015
Robbiki IWW Treatment Plant
Location: 10th of Ramadan City
Capacity: 3000 m3 /day
Scope of Work:
Civil works for the treatment process stages
Commissioning and start-up on 2017
Fayed Water Pumping Station
5 Split casing units
Q= 630 m 3 / hr
H = 150 m
Type: Apollo - Germany
Scope of work:
Supply equipment
Supervision of erection
Al MAX Pumping Station
Scope of Work:
Supply, erection, and startup,
of 4 gearboxes c/w
couplings
and
instruments
Power: 1200 KW single stage
Speed: 990/196.04 RPM
Gear Ratio: 5,05:1
Mounting: Inclined 45°
El Hammam Pipe lines
Location: South of Dubba, Alexandria
Media Irrigation water:
- First sector: 4 steel pipelines, DN 3000mm,
Length 1900 m /each - Second Sector: 6 steel pipelines, DN 3000 mm,
Length 1200 m / each - Two HDPE pipelines, DN 3000 mm,
Length 1515 m / each - Slowdown chamber,
-
Concrete Construction:
Dimensions: 70 m*25 m*8m
Steel rebars: 450 ton
Concrete: 3000 m 3
-
Electromechanical:
Electric operation Penstocks,
Size: 3000 mm, 6 Pcs
2200 mm, 10 Pcs
-
El Maamora Pipe Lines
Location: Alexandria City
Media: Domestic Wastewater
Main force HDPE pipeline, DN 1000 mm, Length 2100 m
Pipe jacking, DN 1000 mm, Length 60 m
Pipe directional drilling, DN 1000 mm, Length 1200 m
El Salam Factory for Polyethylene, PVC, and PP Pipes
It cotains the following:
- Steel structures hangars ;
- 6 hangars with different sizes, for PE,
PVC, and PP pipes production lines - 4 hangars with varying sizes
as raw material storage. - 8 hangars with varying sizes for workshop facilities.
- 6 hangars with different sizes, for PE,
- Two galvanized steel silos ;
- Diameter 5.45 m, height 11m
- Diameter 3.10m, height 9 m
